Your Trusted Partner for OEM PCBA Services in Vietnam

Experience the Efficiency of OEM PCBA Manufacturing

We understand the importance of reliable and high-quality PCBAs for your electronic products. That's why we offer comprehensive OEM PCBA services, catering to your specific needs and ensuring a seamless manufacturing process.

Leverage Our Expertise

  • Turnkey Solutions: We manage the entire PCBA manufacturing process, from material procurement and component assembly to testing and final delivery.

  • Cost-Effectiveness: Benefit from our economies of scale and efficient production lines to optimize your project budget.

  • Quality Assurance: Our commitment to quality is unwavering. We implement stringent quality control measures throughout the entire process, ensuring your PCBAs meet the highest standards.

  • IP Protection: We understand the importance of intellectual property. We have robust confidentiality measures in place to protect your designs.

  • Flexibility and Scalability: Whether you require high-volume production or low-quantity prototypes, we can adapt to your needs.

  • Global Support: Our team is dedicated to providing exceptional customer service throughout the entire process.

Why Choose us for OEM PCBA Manufacturing?

  • Over 15 Years of Experience: We have a proven track record of success in delivering high-quality PCBAs to satisfied customers worldwide.

  • Advanced Technology: Our state-of-the-art SMT lines ensure precise and efficient assembly of even the most complex PCBAs.

  • Dedicated Engineering Team: Our team of experienced engineers is here to collaborate with you every step of the way, from design review to production optimization.

  • Comprehensive Certifications: We are ISO 9001 certified and can assist with obtaining other necessary certifications for your products.

Ready to Get Started?

Contact us today to discuss your OEM PCBA requirements. We are confident that we can be your reliable partner for success. Let us help you bring your electronic vision to life.

Category

Description

Capability

File Formats

Gerber files- preferred

Gerber file 274-X or ODB++

  Drill file

  3.3  leading  mm

Size

Max. finished PCB dimensions

  400mm x 1200mm – Single/ Double-sided

  600mm x 700mm – Multilayer

Board Thickness

  Standard

  1.6mm ±10%

Min.

  0.6mm ±10%

Max.

  3.2mm ±10%

  Bow and twist

  0.50%

Copper Thickness

Outer Cu weight

  0.5oz-12oz

  Inner Cu weight

  0.5oz-12oz

Laminate Materials

  FR4(KB, ILM, Shengyi, Huazheng new material ) ,
   High TG, Aluminum plate( Taiwan)


Board Cutting

Max. number of layers

  20

Min. thickness for inner layers (Cu thickness are
   excluded)

  0.05mm

Drilling

Min. size

  0.20mm

Max. size

  6.00mm

Drill Deviation

  ±0.075mm

NPTH hole tolerance

  ±0.05mm

Angle of Countersink

  45°

PTH

Min. hole size

  0.20mm

Aspect ratio

  8:1

Etching

Trace width tolerance

  ±20%

Min. trace width / space (1oz finished Cu weight
starting from 1/3oz)

  75um/75um  (3mil/3mil)

Min. trace width / space  (1oz finished Cu weight
starting from 1/2oz)

  89um/89um  (3.5mil/3.5mmil)

Min. trace width / space (2oz finished Cu weight)

  150um/150um  (6mil/6mil)

Solder Mask

 Color

Green,White,Black,Red,Blue,Etc.

Min. solder mask clearance

  3mil

Thickness

  Line angle:8um(min),Linear plane:10um(min),
   base material:20-50um

Silkscreen

Color

White,Black,Etc.

Min. trace width

  100um 4mil

Min. size

  0.7mm 28mil

Test

AOI

  100%

Flying Probe Tester

  Sample 100%

E-test

Mass order 100%

Controlled Impedance

Tolerance

  +/-10%

Impedance tester

  Test impedance module

Profile

Tolerance

  ±0.10mm

V—CUT Depth

  ±0.10mm

V—CUT angle deviation

  30°

Semi-hole

Minimum half hole:0.40mm

Surface Finish

HASL,Immersion gold(ENIG),OSP



PCBA Capability

ISO 9001:2015 certification.
Ability to handle small quantities and provide quick turnaround.
Installation and rework of BGA and Micro-BGA components with 100% X-Ray Inspection and Automated Optical Inspection.
RoHS and Lead-Free assembly compliance.
Expertise in single or double-sided mixed technology PCB assembly.
Capability to work with both consigned components and provide turnkey solutions.
Proficiency in handling a wide range of devices, including various types of BGAs, CGAs, QFNs, DFNs, CSPs, and SONs.
Adherence to strict process requirements to ensure product quality and reliability.
With UL, CE, FCC, and Rohs Approval
Professional Surface-mounting and Through-hole soldering Technology.
SMT nitrogen reflow technology and DIP wave soldering technology.
Various packages like 1206,0805,0603 BGA components SMT technology.
ICT (In Circuit Test), FCT (Functional Circuit Test) Technology.
HDI board placement technology capacity.
